1217-5/8ECG RHP

All dimensions

1. Inner (d) MM 15,875
2. Outer (D) MM 40
3. Width (B) MM 28,6
4. Inner (d) Inch 0.625
5. Outer (D) Inch 1.5748
6. Width (B) Inch 1.126

Suffix description

1. EC Excentric Collar Lock With Flush Inner Ring On One Side
2. G Regreasing Facility With Lubricating Groove And Hole In The Outer Ring

Technical details

1. Availability 0 pcs
2. Brand RHP
3. Item number 1217-5/8ECG RHP
4. EAN 00747023042692
5. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.11

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment
