110BER10STYNSULP3 NSK

All dimensions

1. Inner (d) MM 110
2. Outer (D) MM 170
3. Width (B) MM 28
4. Inner (d) Inch 4.3307
5. Outer (D) Inch 6.6929
6. Width (B) Inch 1.1024

Suffix description

1. S All Steel Bearing (SUJ2)
2. TYN This Special Design Allows The Bearing To Have Lower Friction And Lower Noise. The Temperature Rise Of The Bearing With A TYN Cage Is Lower Than That With A Phenolic Cage At A Rotational Speed Lower Than 1.4 Million DmN* ("Dm
3. N Pitch Circle Diameter Of Rolling Elements (mm)" x "Speed" (Min-1"))
4. SUL Single Bearing, Universally Ground, Light Preload
5. P3 Dimensional Accuracy P4, Running Accuracy P2

Technical details

1. Availability 1 pc
2. Brand NSK
3. Item number 110BER10STYNSULP3 NSK
4. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 2.133

Product Properties

1. Seal No Seal
2. Cage Type P - Plastic Molded Cage
3. Precision Dim. Acc. P4, Run. Acc. P2
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
