32018X-90KC5 Timken

Alle Abmessungen

1. Innen (d) mm 90
2. Außen (D) mm 140
3. Breite (B) mm 32
4. Innen (d) Zoll 3.5433
5. Außen (D) Zoll 5.5118
6. Breite (B) Zoll 1.2598

Suffixbeschreibungen

1. X (Cone/Inner Race And Cup/Outer Race) The Suffix 'X' Has Two Meanings: 1) Special Feature Bearing (Non-Interchangeable With Bearings Having The Same Basic Part Number). 2) ISO Bearing With Same Boundary Dimensions As Basic Part Number But With Different Internal Geometry, Yielding Increased Rating
2. 90KC5 Inspection Code. (Can Be Used As Standard)

Technische Daten

1. Verfügbarkeit 12 St.
2. Marke Timken
3. Item number 32018X-90KC5 Timken
4. Also known as 32018X
   SET1048

5. EAN 0053893832470
6. Category Kegelrollenlager einreihig

Gewicht und Abmessungen

1. Gewicht (kg) 1.8

Produkteigenschaften

1. Präzision Standardpräzision
