ZKLR1547-2RS-A INA

Afmetingen

1. Binnenmaat (d) mm 15,00
2. Buitenmaat (D) mm 38,45
3. Breedte (B) mm 24,00
4. Binnenmaat (d) inch 0.5906
5. Buitenmaat (D) inch 1.5138
6. Breedte (B) inch 0.9449
7. Buitendiameter lagerpot (D) mm 38,45
8. Breedte binnenring (B) mm 22,00

Suffix-omschrijving

1. 2RS Lip Seal At Both Sides Of The Bearing, Axial Fitting
2. A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

Technische specificaties

1. Beschikbaarheid 6 stuks
2. Merk INA
3. Item number ZKLR1547-2RS-A INA
4. Also known as 0628366170000

5. EAN 4012802825756
6. Category Tweerijig hoekcontactkogellager

Gewicht en afmetingen

1. Gewicht (kg) 0.14

Producteigenschappen

1. Boring C - cilindrische boring
2. Afdichting 2RS - rubberen afdichting aan twee zijden
3. Type kooi S - stalen of standaard kooi
4. Externe aanpassing Geen Externe Aanpassing
5. Interne radiale speling Cn normale interne speling
6. Precisie Standaardprecisie
7. Smering Standaard smering
8. Warmtestabilisatie Geen warmtestabilisatie - temperaturen tot 120 °C
9. Gedeelde binnenring/buitenring Gedeelde binnenring

Data van Schaeffler (medias)

1. Basis dynamische axiale belasting (C a) "16400.0000"
2. Radial Static Load Rating C0r (N) 10700
3. Radial Dynamic Load Rating Cr (N) 16700
4. Axial Static Load Rating C0a (N) 22400
5. Basis statische axiale belasting (C 0a) "22400.0000"
6. Basis statische radiale belasting (C 0r) "10700.0000"
7. Axial Dynamic Load Rating Ca (N) 16400
8. ECLASS number 23-05-16-02
9. ECLASS2 number 23-05-16-02
10. Medias omschrijving Angular contact ball bearing units ZKLR..-2RS, double direction, for screw mounting, lip seals on both sides

Downloads en links

1. Link to manufacturer Link to manufacturer
