SL024918-A-C3 INA

Afmetingen

1. Binnenmaat (d) mm 90,00
2. Buitenmaat (D) mm 125,00
3. Breedte (B) mm 35,00
4. Binnenmaat (d) inch 3.5433
5. Buitenmaat (D) inch 4.9213
6. Breedte (B) inch 1.3780
7. Breedte (b) mm 35,00

Suffix-omschrijving

1. A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
2. C3 Internal Clearance Larger Than Normal

Technische specificaties

1. Beschikbaarheid 2 stuks
2. Merk INA
3. Item number SL024918-A-C3 INA
4. Also known as 0001236500030
   NNCL4918V/C3

5. EAN 4012802554137
6. Category Tweerijig cilinderrollager

Gewicht en afmetingen

1. Gewicht (kg) 1.35

Producteigenschappen

1. Boring C - cilindrische boring
2. Afdichting Geen afdichting
3. Type kooi FC - volrollig, geen kooi
4. Externe aanpassing Geen Externe Aanpassing
5. Interne radiale speling C3 interne speling (hoger dan Cn)
6. Precisie Standaardprecisie
7. Warmtestabilisatie Geen warmtestabilisatie - temperaturen tot 120 °C

Data van Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 290000
2. Radial Dynamic Load Rating Cr (N) 153000
3. Basis statische radiale belasting (C 0r) "290000.0000"
4. Grenstoerental (n G) "3050.0000"
5. Referentiesnelheid (n ϑr) "1870.0000"
6. ECLASS number 23-05-09-01
7. ECLASS2 number 23-05-09-01
8. Medias omschrijving Cylindrical roller bearing SL02..-A, full complement roller set, two-row, non-locating bearing, 0 ribs on outer ring (smooth), 3 ribs on inner ring, type SL02
