SCH1016 INA

Afmetingen

1. Binnenmaat (d) mm 15,875
2. Buitenmaat (D) mm 22,225
3. Breedte (B) mm 25,4
4. Binnenmaat (d) inch 0.625
5. Buitenmaat (D) inch 0.875
6. Breedte (B) inch 1
7. Diameter onderrol (F w) mm 15,875
8. Breedte (C) mm 25,4

Suffix-omschrijving

1. B The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

Technische specificaties

1. Beschikbaarheid 41 stuks
2. Merk INA
3. Item number SCH1016 INA
4. Also known as 0060113060000

5. EAN 4047643193542
6. Category Naaldlager en toebehoren

Gewicht en afmetingen

1. Gewicht (kg) 0.025

Producteigenschappen

1. Afdichting Geen afdichting

Data van Schaeffler (medias)

1. Basis statische radiale belasting (C 0r) 28000
2. Grenstoerental (n G) 15300
3. ECLASS number 23-05-09-05
4. ECLASS2 number 23-05-09-05

Downloads en links

1. Link to manufacturer Link to manufacturer
