NU2234EMC3U1U303 NSK

Afmetingen

1. Binnenmaat (d) mm 170,00
2. Buitenmaat (D) mm 310,00
3. Breedte (B) mm 86,00
4. Binnenmaat (d) inch 6.6929
5. Buitenmaat (D) inch 12.2047
6. Breedte (B) inch 3.3858

Suffix-omschrijving

1. E Increased Load Capacity
2. M Machined Brass Cage, Located On The Rolling Elements
3. C3 Internal Clearance Larger Than Normal
4. U1 Special Quality Control Specification
5. U303 The Code U303 In The Article Number Of An NSK Bearing Shows That It Was Specially Developed And Produced For Use In Wind Power Technology. These Wind Turbine Bearings Are Made From Premium, High-Purity Bearing Steels And Special Steels Used Exclusively By NSK. They Are Also Assembled In Separate Production Areas And Subject To Special Packaging Regulations, Which Prevent Contamination

Technische specificaties

1. Beschikbaarheid 3 stuks
2. Merk NSK
3. Item number NU2234EMC3U1U303 NSK
4. Category Eenrijig cilinderrollager

Gewicht en afmetingen

1. Gewicht (kg) 29.6

Producteigenschappen

1. Boring C - cilindrische boring
2. Afdichting Geen afdichting
3. Type kooi M - messing kooi
4. Externe aanpassing Geen Externe Aanpassing
5. Interne radiale speling C3 interne speling (hoger dan Cn)
6. Precisie Standaardprecisie
7. Warmtestabilisatie Geen warmtestabilisatie - temperaturen tot 120 °C
