NU210-E-XL-M1-F1-J20AA-R65-80NA FAG

Afmetingen

1. Binnenmaat (d) mm 50
2. Buitenmaat (D) mm 90
3. Breedte (B) mm 20
4. Binnenmaat (d) inch 1.9685
5. Buitenmaat (D) inch 3.5433
6. Breedte (B) inch 0.7874
7. Breedte (b) mm 20

Suffix-omschrijving

1. E Increased Load Capacity
2. XL X-Life
3. M1 Solid Brass Cage, Two Piece, Roller Guided
4. F1 FAG Manufacturing And Inspection Specification For Cylindrical Roller Bearings In Traction Motors Which Considers, Among Others, The Requirements According To Din 43283 "Cylindrical Roller Bearings For Electric Traction"
5. J20AA Current Insulation, Outer Ring Ceramic Coated, Breakdown Voltage DC: 3.000 V, Layer Thickness 200 μm, Ohmic Resistance: 50 MΩ. Speciality Humid Environments
6. R65-80 Radial Clearance In μm
7. NA No Special Meaning For Cylindrical Bearing

Technische specificaties

1. Beschikbaarheid 1 stuk
2. Merk FAG
3. Item number NU210-E-XL-M1-F1-J20AA-R65-80NA FAG
4. Also known as 0390426004033

5. EAN 4012802115581
6. Category Eenrijig cilinderrollager

Gewicht en afmetingen

1. Gewicht (kg) 0.532

Producteigenschappen

1. Boring C - cilindrische boring
2. Afdichting Geen afdichting
3. Type kooi M - messing kooi
4. Externe aanpassing Geen Externe Aanpassing
5. Interne radiale speling Cn normale interne speling
6. Precisie Bearings for Traction Motors
7. Warmtestabilisatie Geen warmtestabilisatie - temperaturen tot 120 °C

Data van Schaeffler (medias)

1. Basis statische radiale belasting (C 0r) 69000
2. Grenstoerental (n G) 14500
3. Referentiesnelheid (n ϑr) 6600
