NJ2332-E-XL-MPAX-ILR-J30PC-C3 FAG

Afmetingen

1. Binnenmaat (d) mm 160
2. Buitenmaat (D) mm 340
3. Breedte (B) mm 114
4. Binnenmaat (d) inch 6.2992
5. Buitenmaat (D) inch 13.3858
6. Breedte (B) inch 4.4882

Suffix-omschrijving

1. E Increased Load Capacity
2. XL X-Life
3. MPAX Rib-Guided Single-Piece Solid Brass Cage Is A Further Development Of FAG Cage Types MPA And MP1A And Will Replace These Types Successively. It Has Greater Durability With Regard To Shock Loads And Vibrations Than It's Predecessors And It's Especially Well Suited For Applications Involving High Loads
4. ILR Increased Load Rating
5. J30PC Rings And Rolling Elements With Black Oxide Coating (Durotect B)
6. C3 Internal Clearance Larger Than Normal

Technische specificaties

1. Beschikbaarheid 1 stuk
2. Merk FAG
3. Item number NJ2332-E-XL-MPAX-ILR-J30PC-C3 FAG
4. Also known as 3004683500030

5. EAN 4064328047594
6. Category Eenrijig cilinderrollager

Gewicht en afmetingen

1. Gewicht (kg) 48.1

Producteigenschappen

1. Boring C - cilindrische boring
2. Afdichting Geen afdichting
3. Type kooi MA - messing kooi, gecentreerd op buitenring
4. Externe aanpassing Geen Externe Aanpassing
5. Interne radiale speling C3 interne speling (hoger dan Cn)
6. Precisie Durotect B Coating
7. Warmtestabilisatie Geen warmtestabilisatie - temperaturen tot 120 °C
