K30X35X13-B/-3-5 INA

Afmetingen

1. Binnenmaat (d) mm 30,00
2. Buitenmaat (D) mm 35,00
3. Breedte (B) mm 13,00
4. Binnenmaat (d) inch 1.1811
5. Buitenmaat (D) inch 1.3780
6. Breedte (B) inch 0.5118
7. Buitendiameter naaldlagercomplement (E w) mm 35,00
8. Breedte (B c) mm 13,00

Suffix-omschrijving

1. B The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
2. /-3-5 Micron - Needle Sort

Technische specificaties

1. Beschikbaarheid 0 stuks
2. Merk INA
3. Item number K30X35X13-B/-3-5 INA
4. EAN 4012802724271
5. Category Naaldlager en toebehoren

Gewicht en afmetingen

1. Gewicht (kg) 0.0138

Producteigenschappen

1. Afdichting Geen afdichting

Data van Schaeffler (medias)

1. Basis statische radiale belasting (C 0r) "25500.0000"
2. Grenstoerental (n G) "15100.0000"
3. Referentiesnelheid (n ϑr) "8400.0000"
4. ECLASS number 23-05-09-04
5. ECLASS2 number 23-05-09-04

Downloads en links

1. Link to manufacturer Link to manufacturer
