GYE20-KRR-B-VA-HLA INA

Afmetingen

1. Binnenmaat (d) mm 20
2. Buitenmaat (D) mm 47
3. Breedte (B) mm 31
4. Binnenmaat (d) inch 0.7874
5. Buitenmaat (D) inch 1.8504
6. Breedte (B) inch 1.2205
7. Buitendiameter (D SP) mm 47
8. Breedte (b) mm 31

Suffix-omschrijving

1. KRR Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
2. B Bearing With Spherical Outer Ring
3. VA Corrosion-Resistant Design Made From High Alloy Rolling Bearing Steel
4. HLA Factory Location Code, No Additional Meaning. Can Be Used As Standard

Technische specificaties

1. Beschikbaarheid 60 stuks
2. Merk INA
3. Item number GYE20-KRR-B-VA-HLA INA
4. Also known as 0512083690000
   GYE20-KRR-B-VA
   YAR204-2F/HV

5. EAN 4012802631791
6. Category Lagers voor behuizingen

Gewicht en afmetingen

1. Gewicht (kg) 0.148

Producteigenschappen

1. Afdichting 2F - standaard afdichting voor Y-lagers
2. Smering Standaard smering
3. Speciale behandeling Roestvrijstalen lager

Data van Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 6300
2. Radial Dynamic Load Rating Cr (N) 12300
3. ECLASS number 23-05-08-02
4. ECLASS2 number 23-05-08-02
5. Medias omschrijving Radial insert ball bearing GYE..-KRR-B-VA

Downloads en links

1. Link to manufacturer Link to manufacturer
