GIHNRK16-LO-A INA

Afmetingen

1. Buitenmaat (D) mm 40
2. Breedte (B) mm 16
3. Buitenmaat (D) inch 1.5748
4. Breedte (B) inch 0.6299
5. Buitendiameter lager (D) mm 28

Suffix-omschrijving

1. LO Sliding Contact Surface Is Steel/Steel, Inner Ring Extended On Both Sides, Single Axial Split In Outer Ring
2. A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

Technische specificaties

1. Beschikbaarheid 0 stuks
2. Merk INA
3. Artikelnummer GIHNRK16-LO-A INA
4. Ook bekend als 0066344940000
   SIQG16ES
   TAPR16CE

5. EAN 4012802525571
6. Categorie Stangkop

Gewicht en afmetingen

1. Gewicht (kg) 0.196

Producteigenschappen

1. Afdichting Geen afdichting
2. Contactmateriaal Staal op staal

Data van Schaeffler (medias)

1. Radiale speling (G r) 0,03 - 0,082
2. Radial Static Load Rating C0r (N) 35400
3. ECLASS number 23-05-01-05
4. ECLASS2 number 23-05-01-05
5. Medias omschrijving Hydraulic rod end, with thread clamping device, right hand thread, requiring maintenance, sliding contact surface: steel/steel, DIN 24338 ISO 6982, open design
