7013CTYNSULP5 NSK

Afmetingen

1. Binnenmaat (d) mm 65
2. Buitenmaat (D) mm 100
3. Breedte (B) mm 18
4. Binnenmaat (d) inch 2.5591
5. Buitenmaat (D) inch 3.937
6. Breedte (B) inch 0.7087

Suffix-omschrijving

1. C 15° Contact Angle
2. TYN This Special Design Allows The Bearing To Have Lower Friction And Lower Noise. The Temperature Rise Of The Bearing With A TYN Cage Is Lower Than That With A Phenolic Cage At A Rotational Speed Lower Than 1.4 Million DmN* ("Dm
3. N Pitch Circle Diameter Of Rolling Elements (mm)" x "Speed" (Min-1"))
4. SUL Single Universal, Light Preload
5. P5 Dimensional And Running Accuracy To ISO Tolerance Class 5

Technische specificaties

1. Beschikbaarheid 1 stuk
2. Merk NSK
3. Item number 7013CTYNSULP5 NSK
4. Also known as 7013CTYNSUL

5. Category Hoekcontactkogellager eenrijig

Gewicht en afmetingen

1. Gewicht (kg) 0.435

Producteigenschappen

1. Afdichting Geen afdichting
2. Type kooi P - kunststof gegoten kooi
3. Precisie P5 precisie (hoger dan P6)
4. Contacthoek 15 graden
5. Koppeling G - universele paren
6. Axiale speling / voorspanning GA - Light Preload
7. Smering Standaard smering
