6336MRC4P5BX26U3U303 NSK

Afmetingen

1. Binnenmaat (d) mm 180
2. Buitenmaat (D) mm 380
3. Breedte (B) mm 75
4. Binnenmaat (d) inch 7.0866
5. Buitenmaat (D) inch 14.9606
6. Breedte (B) inch 2.9528

Suffix-omschrijving

1. MR Roller Guided Machined Brass Cage
2. C4 Bearing Internal Clearance Greater Than C3
3. P5B Inner Ring With P5 Running Accuracy, Mark High And Low Points Of Eccentricity On Face Of Rings
4. X26 Dimensionally Stabilized For Operating Temperature Of 150°C Max
5. U3 Special Quality Control Specification
6. U303 The Code U303 In The Article Number Of An NSK Bearing Shows That It Was Specially Developed And Produced For Use In Wind Power Technology. These Wind Turbine Bearings Are Made From Premium, High-Purity Bearing Steels And Special Steels Used Exclusively By NSK. They Are Also Assembled In Separate Production Areas And Subject To Special Packaging Regulations, Which Prevent Contamination

Technische specificaties

1. Beschikbaarheid 78 stuks
2. Merk NSK
3. Item number 6336MRC4P5BX26U3U303 NSK
4. Also known as 6336FY C4
   6336M P54
   6336M.C4
   6336M/C4C02S0
   6336M/P54
   6336-MB-C4-T52BE-S0
   6336-M-C4
   6336-M-P54
   6336-M-P5-C4

5. Category Eenrijig groefkogellager

Gewicht en afmetingen

1. Gewicht (kg) 41

Producteigenschappen

1. Boring C - cilindrische boring
2. Afdichting Geen afdichting
3. Type kooi M - messing kooi
4. Externe aanpassing Geen Externe Aanpassing
5. Interne radiale speling C4 interne speling (hoger dan C3)
6. Precisie Inner Accuracy (1/4 RBEC.1)
7. Smering Standaard smering
8. Warmtestabilisatie S0 - temperaturen tot 150 °C
9. Speciale behandeling Geen speciale behandeling
