6307-2RSR FAG

Rubber seal (2 sides) 35x80x21mm

Voorraad
1.147 stuks uit voorraad leverbaar
Merk FAG
Artikelnummer 6307-2RSR FAG
Binnendiameter 35,00mm
Buitendiameter 80,00mm
Breedte 21,00mm
Productbeschrijving
The 6307-2RSR FAG is a deep groove ball bearing with a single row design. Deep groove ball bearings have a straight forward design, are robust in operation and are easy to maintain. Deep groove ball bearings reduce rotational friction and support both radial and axial loads.

The 6307-2RSR FAG is suitable for high speeds and can operate with low noise.

The dimensions of the 6307-2RSR FAG are: Bore (or inner diameter) 35mm, Outer diameter 80mm and Width (or thickness) 21mm.

6300 serie
The 6307-2RSR FAG is part of the popular 6300 serie which contain extra light ball bearings and are perfect for limited space applications.The 6300 serie is used in a wide range of industrial processes as well as DIY applications like: skateboards, inline skates, bicycles, washing and drying machines.

Seal
The 2RSR suffix indicates that the bearing has a rubber seal on both sides. If necessary the seals can easily removed if the application requires only 1 seal. The rubber seal protects the ingress of moisture, dust or other dirt. The bearings are filled with a high quality grease and are lubricated for life.

About FAG
FAG is a brand of the Schaeffler Group Industrial originated in Germany. The Schaeffler Group produces two major bearing brands: FAG and INA. FAG is known for its strength in innovation, high-quality standards and wide portfolio of bearings and related products. If you choose to buy a product from FAG you are ensured of a top quality product.
Read more Toon minder
Hulp nodig?

Downloads en links

Vergelijkbaar met: 6307-2RSR FAG

Vergelijkbare producten worden geladen

Productinformatie/ specificaties

Afmetingen

  1. Binnenmaat (d) mm 35,00
  2. Buitenmaat (D) mm 80,00
  3. Breedte (B) mm 21,00
  4. Binnenmaat (d) inch 1.3780
  5. Buitenmaat (D) inch 3.1496
  6. Breedte (B) inch 0.8268
  7. Breedte (b) mm 21,00

Suffix-omschrijving

  1. 2RSR Rubber Seals At Each Side Of The Bearing

Technische specificaties

  1. Beschikbaarheid 1.147 stuks
  2. Merk FAG
  3. Item number 6307-2RSR FAG
  4. Also known as 0167232440000
    6307-2RS
    6307-2RS1
  5. EAN 4012801074094
  6. Category Eenrijig groefkogellager

Gewicht en afmetingen

  1. Gewicht (kg) 0.465

Producteigenschappen

  1. Boring C - cilindrische boring
  2. Afdichting 2RS - rubberen afdichting aan twee zijden
  3. Type kooi S - stalen of standaard kooi
  4. Externe aanpassing Geen Externe Aanpassing
  5. Interne radiale speling Cn normale interne speling
  6. Precisie Standaardprecisie
  7. Smering Standaard smering
  8. Warmtestabilisatie Geen warmtestabilisatie - temperaturen tot 120 °C
  9. Speciale behandeling Geen speciale behandeling

Data van Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 19100
  2. Radial Dynamic Load Rating Cr (N) 35500
  3. Basis statische radiale belasting (C 0r) "19100.0000"
  4. Grenstoerental (n G) "5400.0000"
  5. ECLASS number 23-05-08-01
  6. ECLASS2 number 23-05-08-01
  7. Medias omschrijving Deep groove ball bearing 63..-2RSR, single row, cf. DIN 625-1

Downloads en links

  1. Link to manufacturer Link to manufacturer
