6203/C3 SKF

Open Higher (internal) clearance 17x40x12mm

Voorraad
niet op voorraad
Merk SKF
Artikelnummer 6203/C3 SKF
Binnendiameter 17mm
Buitendiameter 40mm
Breedte 12mm
Productbeschrijving
The 6203/C3 SKF is a deep groove ball bearing with a single row design. Deep groove ball bearings have a straight forward design, are robust in operation and are easy to maintain. Deep groove ball bearings reduce rotational friction and support both radial and axial loads.

The 6203/C3 SKF is suitable for high speeds and can operate with low noise.

The dimensions of the 6203/C3 SKF are: Bore (or inner diameter) 17mm, Outer diameter 40mm and Width (or thickness) 12mm.

6200 serie
The 6203/C3 SKF is part of the popular 6200 serie which contain extra light ball bearings and are perfect for limited space applications.The 6200 serie is used in a wide range of industrial processes as well as DIY applications like: skateboards, inline skates, bicycles, washing and drying machines.

Internal play
The C3 in the product name means that this bearing has a higher (internal) clearance than normal. The C3 clearance is most frequently used for this type of bearings. The extra internal clearance allows expansion due to high speeds or temperatures.

About SKF
SKF is the most renowned producer of bearings worldwide. SKF stands for outstanding quality and has been a forerunner in the production of bearings and related items for years. By buying a SKF bearing you are sure to buy top quality.
Read more Toon minder
Hulp nodig?

Vergelijkbaar met: 6203/C3 SKF

Vergelijkbare producten worden geladen

Productinformatie/ specificaties

Afmetingen

  1. Binnenmaat (d) mm 17
  2. Buitenmaat (D) mm 40
  3. Breedte (B) mm 12
  4. Binnenmaat (d) inch 0.6693
  5. Buitenmaat (D) inch 1.5748
  6. Breedte (B) inch 0.4724

Suffix-omschrijving

  1. C3 Internal Clearance Larger Than Normal

Technische specificaties

  1. Beschikbaarheid 0 stuks
  2. Merk SKF
  3. Item number 6203/C3 SKF
  4. EAN 7316571367316
  5. Category Eenrijig groefkogellager

Gewicht en afmetingen

  1. Gewicht (kg) 0.062

Producteigenschappen

  1. Boring C - cilindrische boring
  2. Afdichting Geen afdichting
  3. Type kooi S - stalen of standaard kooi
  4. Externe aanpassing Geen Externe Aanpassing
  5. Interne radiale speling C3 interne speling (hoger dan Cn)
  6. Precisie Standaardprecisie
  7. Smering Standaard smering
  8. Warmtestabilisatie Geen warmtestabilisatie - temperaturen tot 120 °C
  9. Speciale behandeling Geen speciale behandeling
