6201-2RSLTN9/HC5C3WT SKF

Afmetingen

1. Binnenmaat (d) mm 12
2. Buitenmaat (D) mm 32
3. Breedte (B) mm 10
4. Binnenmaat (d) inch 0.4724
5. Buitenmaat (D) inch 1.2598
6. Breedte (B) inch 0.3937

Suffix-omschrijving

1. 2RSL Sheet Steel Reinforced Low Friction Seal Of Acrylonitrile-Butadiene Rubber (NBR) On Both Sides Of The Bearing
2. TN9 Injection Moulded Snap-Type Cage Of Glass Fibre Reinforced Polyamide 6,6, Ball Centered
3. HC5 Rolling Elements Of Silicon Nitride
4. C3 Internal Clearance Larger Than Normal
5. WT Grease Fill For Low As Well As High Temperature e.g. Range -40 ~ 160°C. WT Or A Two-Figure Number Following WT Identifies The Actual Grease. An Additional Letter Or Letter/ Figure Combination As Mentioned Under “HT” Identifies Filling Degrees Other Than Standard

Technische specificaties

1. Beschikbaarheid 64 stuks
2. Merk SKF
3. Item number 6201-2RSLTN9/HC5C3WT SKF
4. Also known as 6201-2RSLTN9/HC5C3

5. EAN 7316572070895
6. Category Eenrijig groefkogellager

Gewicht en afmetingen

1. Gewicht (kg) 0.033

Producteigenschappen

1. Boring C - cilindrische boring
2. Afdichting 2RL - Low Friction NBR-seal
3. Type kooi P - kunststof gegoten kooi
4. Externe aanpassing Geen Externe Aanpassing
5. Interne radiale speling C3 interne speling (hoger dan Cn)
6. Precisie H5 - Ceramic Ball Set
7. Smering 2 - High Temperature Grease
8. Warmtestabilisatie Geen warmtestabilisatie - temperaturen tot 120 °C
9. Speciale behandeling Geen speciale behandeling
