6200-C-Z-HRS-L069-C3 FAG

Afmetingen

1. Binnenmaat (d) mm 10
2. Buitenmaat (D) mm 30
3. Breedte (B) mm 9
4. Binnenmaat (d) inch 0.3937
5. Buitenmaat (D) inch 1.1811
6. Breedte (B) inch 0.3543

Suffix-omschrijving

1. C Deep Groove Ball Bearings Of Generation C, Modified Internal Construction
2. Z Shield Of Pressed Sheet Steel On One Side Of The Bearing
3. HRS Lip Seal On One Side Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal
4. L069 Insert Bearing Grease For Wide Temperature Range - Polycarbamide Ester Oil - –40°C to +180°C
5. C3 Internal Clearance Larger Than Normal

Technische specificaties

1. Beschikbaarheid 100 stuks
2. Merk FAG
3. Item number 6200-C-Z-HRS-L069-C3 FAG
4. Also known as 0968951870030
   6200-Z

5. EAN 4064327244352
6. Category Eenrijig groefkogellager

Gewicht en afmetingen

1. Gewicht (kg) 0.0314

Producteigenschappen

1. Boring C - cilindrische boring
2. Afdichting HRS-Z - Contact Seal + Steel Seal
3. Type kooi S - stalen of standaard kooi
4. Externe aanpassing Geen Externe Aanpassing
5. Interne radiale speling C3 interne speling (hoger dan Cn)
6. Precisie Standaardprecisie
7. Smering Standaard smering
8. Warmtestabilisatie Geen warmtestabilisatie - temperaturen tot 120 °C
9. Speciale behandeling Geen speciale behandeling
