31314J2/QCL7ADF SKF

Afmetingen

1. Binnenmaat (d) mm 70
2. Buitenmaat (D) mm 150
3. Breedte (B) mm 76
4. Binnenmaat (d) inch 2.7559
5. Buitenmaat (D) inch 5.9055
6. Breedte (B) inch 2.9921

Suffix-omschrijving

1. J2 Pressed Steel Window-Type Cage. A Figure Following The J Indicates A Different Cage Design
2. Q Optimized Contact Geometry And Surface Finish
3. CL7A Standard SKF Quality For Pinion Bearings (Superseded By CL7C) - (100% Interchangeable With Basic Designation)
4. DF Matched Bearing Pair Arranged Face-To-Face. A Figure Combination Immediately Following The DF Identifies The Design Of The Intermediate Ring

Technische specificaties

1. Beschikbaarheid 0 stuks
2. Merk SKF
3. Item number 31314J2/QCL7ADF SKF
4. Also known as 31314A.A100.140.N11CA
   31314DF
   31314J2/QDF

5. EAN 7316570002690
6. Category Gepaard eenrijige kegellager

Gewicht en afmetingen

1. Gewicht (kg) 6.15

Producteigenschappen

1. Interne speling voor gepaard kegelrollager DF-standaard gekoppelde metrische X-opstelling
