Product |
Article Number (Market Facing Number) | 1LE1603-2BB03-4AB4 |
Product Description | SIMOTICS SD MOTOR TYPE: 1CV3220B LOW-VOLTAGE MOTOR, IEC SQUIRREL-CAGE,SELF-VENTIL.,IP55 TEMP. CL. 155(F) ACC.TO 130(B) CAST-IRON HOUSING PERFORMANCE LINE PREMIUM EFFICIENCY IE3, 4POLE * FS225S * 37KW (50HZ) 42.5KW (60HZ) 3 AC 50HZ 400VD/690VY * 3 AC 60HZ 460VD IM B 3, MOTOR PROTECTION WITH 3 PTC THERMISTORS FOR SHUTDOWN TERMINAL BOX AT TOP |
Product family | Cast-iron series 1LE1503/1LE1603 Basic/Performance Line - Self-vent. |
Product Lifecycle (PLM) | PM300:Active Product |
Price data |
Price Group / Headquarter Price Group | M2P / 3Z1 |
List Price | Show prices |
Customer Price | Show prices |
Metal Factor | N-W----- |
Delivery information |
Export Control Regulations | AL : N / ECCN : N |
Delivery Time | 15 Day/Days |
Net Weight (kg) | 285,000 Kg |
Product Dimensions (W x L x H) | Not available |
Packaging Dimension | Not available |
Package size unit of measure | Not available |
Quantity Unit | 1 Piece |
Packaging Quantity | 1 |
Additional Product Information |
EAN | Not available |
UPC | Not available |
Commodity Code | 85015230 |
LKZ_FDB/ CatalogID | D81.1-1/IEC |
Product Group | 5127 |
Country of origin | Czech Republic |
RoHS Conformity Date | Since: 01/12/06 |
Product class | C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. |
Obligation Category for taking back electrical and electronic equipment after use | No obligation to take back electrical and electronic equipment after use |
Classifications |
| | Version | Classification | eClass | 5.1 | 27-02-21-01 | eClass | 6 | 27-02-21-01 | |
